Hinged Valve Outlet (Swingout Elbow) – Hinged Valve Outlet | 7″-5.75″ | Putz Female CCI | BA: 90 | 300x545mm | HT

Description

Hinged Valve Outlet | 7″-5.75″ | Putz Female CCI | BA: 90 | 300x545mm | HT Backend components are designed for the highest pressure applications in the pumping system, along with features that result in a long product life.
INLET DIAMETER [IN] – DN180/7″, OUTLET DIAMETER [IN] – DN150/5.75″, ANGLE [DEGREES] – 90°, END STYLE – Putz 6″ HP Female CCI, HEAT TREATMENT – Heat Treated, Center-to-Face – Backend Outlet Elbow – 300 x 545mm, WALL THICKNESS [IN/MM] – Biased toward high wear areas, MODEL – Cast Steel Elbow, PRESSURE RATING [BAR/PSI] – 130 / 1885,
