Esser 900 Elbow/Bend – Esser 900 Elbow | ID: DN180 / DN150 | BA: 90 | Schwing MaleSchwing Male | 371x431mm

Description

Esser 900 Elbow | ID: DN180 / DN150 | BA: 90 | Schwing MaleSchwing Male | 371x431mm Backend components are designed for the highest pressure applications in the pumping system, along with features that result in a long product life.
INLET DIAMETER [IN] – DN180/7″, OUTLET DIAMETER [IN] – DN150/5.75″, ANGLE [DEGREES] – 90°, END STYLE – Schwing Male, Center-to-Face – Backend Outlet Elbow – 371 x 431mm, Wall Thickness – Twin Wall – Biased toward high wear areas, MODEL – Esser 900, Pressure – Meets 85 bar working / 170 bar burst – Yes, Hardness – Up to 67HRc, LINER TYPE – Hardened Steel Liner,
