Pipe Section – CCI-Lined Backend Pipe | ID: DN150/5.75″ | Schwing M/F | OAL: 13.38″ / 340mm | w/ 5″ Metric Port

Description

CCI-Lined Backend Pipe | ID: DN150/5.75″ | Schwing M/F | OAL: 13.38″ / 340mm | w/ 5″ Metric Port Backend components are designed for the highest pressure applications in the pumping system, along with features that result in a long product life.
INSIDE DIAMETER [IN/MM] – DN150/6″, END STYLE – Euro Male / Euro Female, LENGTH [IN/MM] – 13.38″ / 340mm, Wall Thickness – Twin Wall – 9.5mm + 4.6mm, PRESSURE RATING [BAR/PSI] – 85 / 1233, Hardness – 58 to 62 HRc, LINER TYPE – Chrome Carbide Liners, Typical Application – Backend, Special Description – w/ 5″ Metric port,
