Endurance TW250 Boom Pipe – Boom Pipe | ID: DN112/4.4″ | OAL: 100.59″ | WT:3.3mm + 1.8mm | Metric CCI

$783.15

SKU: B44TWA059M Category:

Description

Boom Pipe | ID: DN112/4.4″ | OAL: 100.59″ | WT:3.3mm + 1.8mm | Metric CCI TW250 Boom Pipes have the industry’s thickest liner in a DN112/4.4 Twin-Wall™ System, and use chrome carbide ends to protect the pipe against excessive wear. Best paired with twin wall elbows, reducers, and backend kits.
New boom and deck parts meet or exceed 85 bar working and 170 bar burst pressure ratings, and are tagged with size, part number, weight (FWC) and working pressure.
INSIDE DIAMETER [IN/MM] – DN112/4.4″, END STYLE – Metric CCI, LENGTH [IN/MM] – 100.59″ / 2555mm, Wall Thickness – Twin Wall – 3.3mm + 1.8mm, Wall Type – Twin-Wall™ – Standard Weight, MODEL – TW250 Boom Pipe, Pressure – Meets 85 bar working / 170 bar burst – Yes, PRESSURE RATING [BAR/PSI] – 105 / 1525, Weight – F.W.C. / foot – 23.5 lbs/ft (10.7 kg/ft), Hardness – Up to 68HRc, LINER TYPE – Hardened Steel Liner, Typical Application – Boom,

Additional information

Weight 0.000000000 lbs
