Guardian Plus Deck Pipe – Deck Pipe | ID: DN125/4.8″ | OAL: 140.19″ | WT: 6.6mm/.261″ | Metric CCI | HT

$1,404.25

SKU: BC54E018MH Category:

Description

Deck Pipe | ID: DN125/4.8″ | OAL: 140.19″ | WT: 6.6mm/.261″ | Metric CCI | HT Ultra Plus single wall boom and deck pipe is hardened through a multiple step heat treating process for extended life. Utilizes CCI-Lined weld ends. Best paired with CCI-Lined elbows, reducers and backend kits.
New boom and deck parts meet or exceed 85 bar working and 170 bar burst pressure ratings, and are tagged with size, part number, weight (FWC) and working pressure.
INSIDE DIAMETER [IN/MM] – DN125/4.8″, END STYLE – Metric CCI, LENGTH [IN/MM] – 140.19″ / 3561mm, HEAT TREATMENT – Heat Treated, WALL THICKNESS [IN/MM] – 0.261″ / 6.6mm, Wall Type – Single Wall, MODEL – Guardian Plus Deck Pipe, Pressure – Meets 85 bar working / 170 bar burst – Yes, PRESSURE RATING [BAR/PSI] – 100 / 1450, Weight – F.W.C. / foot – 33.5 lbs/ft (15.2 kg/ft), Weight – Empty / foot – 14.2 lbs/ft (6.4 kg/ft), Hardness – Up to 68HRc, Typical Application – Deck,

Additional information

Weight 0.000000000 lbs
