Guardian Deck Pipe – Deck Pipe | ID: DN125/4.8″ | OAL: 117.91″ | WT:6.6mm/.261″ | Metric CCI | HT

Description

Deck Pipe | ID: DN125/4.8″ | OAL: 117.91″ | WT:6.6mm/.261″ | Metric CCI | HT New boom and deck parts meet or exceed 85 bar working and 170 bar burst pressure ratings, and are tagged with size, part number, weight (FWC) and working pressure.
Ultra III is an induction hardened single-wall pipe with CCI-lined (chrome carbide) weld ends for added pipe end protection. Best matched up with cast manganese elbows, and hardened steel reducers and backend kits.
INSIDE DIAMETER [IN/MM] – DN125/4.8″, END STYLE – Metric CCI, LENGTH [IN/MM] – 117.91″ / 2995mm, HEAT TREATMENT – Heat Treated, WALL THICKNESS [IN/MM] – 0.261″ / 6.6mm, Wall Type – Single Wall, MODEL – Guardian Deck Pipe, Pressure – Meets 85 bar working / 170 bar burst – Yes, Weight – F.W.C. / foot – 33.5 lbs/ft (15.2 kg/ft), Weight – Empty / foot – 14.2 lbs/ft (6.4 kg/ft), Hardness – Up to 57HRc, Typical Application – Deck,
