Placing Elbow/Bend – Placing Elbow/Bend | ID: 3″ | WT:0.25 | BA: 90 | CLR: 4 | HD | 152 x 152mm

Description

Placing Elbow/Bend | ID: 3″ | WT:0.25 | BA: 90 | CLR: 4 | HD | 152 x 152mm Steel laydown/placing line components comes in multiple wall thicknesses, sizes, and configurations to match a multitude of line-pumping applications. Hardened versions are available for longer life.
INSIDE DIAMETER [IN/MM] – 3.00″ / 76mm, ANGLE [DEGREES] – 90°, END STYLE – Hevi-Duty™, Center-to-Face – 90° Elbow – 152 x 152mm, Centerline Radius (CLR) – 4.00″, WALL THICKNESS [IN/MM] – 0.250″ / 6.35mm, PRESSURE RATING [BAR/PSI] – 130 / 1885,
