Reducing Elbow/Bend – Reducing Elbow/Bend | DN100/4″ Hevi-Duty™ – 3″ Hevi-Duty™ | BA: 90 | CLR: 6″

Description

Reducing Elbow/Bend | DN100/4″ Hevi-Duty™ – 3″ Hevi-Duty™ | BA: 90 | CLR: 6″ Steel laydown/placing line components comes in multiple wall thicknesses, sizes, and configurations to match a multitude of line-pumping applications. Hardened versions are available for longer life.
INLET DIAMETER [IN] – DN100/4″, OUTLET DIAMETER [IN] – 3″, ANGLE [DEGREES] – 90°, Inlet End Style – Hevi-Duty™, Outlet End Style – Hevi-Duty™, Center-to-Face – 90° Elbow – 191 x 191mm, Centerline Radius (CLR) – 6.00″, WALL THICKNESS [IN/MM] – Biased toward high wear areas, PRESSURE RATING [BAR/PSI] – 130 / 1885,
